Brief Description
● It is lightweight, small in size and easy to take;
●Digital LCD(with LED backlight)display of SpO2, PR,Pulse Bar;
●Real-time store and recall SpO2 and Pulse Rate value;
●Up to 12 hours of oximetry data storage (Record data once every 2 secon;
●Data record can be uploaded to PC;(Oximeter date manager software available);
●Audible & Visual alarm function, alarm limits adjustable ;
●Power management function, low battery voltage indication;
●Power off automatically without signal for about 1 minute;
●More than 50 hours continuous working time with 3AA alkaline batteries;
●3 AA alkaline or rechargeable batteries or AC/DC adapter (optional);
●Neonate/pediatric/adult probe changeable and optional
Main Technical Parameters
A. Display mode:
segment LCD
B. Power supply requirement:
Supply voltage: 4.5V (3 ×AA size) alkaline battery or Ni-MH Rechargeable Batteries;
Operating current: <50mA
C. SpO2 Parameter Specifications
Measuring range: 70~99%
Accuracy: 70~99% ±3digits
Default alarm limit: 85%
D. Pulse Rate Parameter Specifications
Measuring range: 30bpm~240bpm
Accuracy: ±2bpm or ±2% (whichever is greater)
Default alarm limits: High: 120bpm Low: 50bpm
E. Data Record
The record interval is 2 seconds, that is the oximeter records a group of SpO2 value and PR value every 2 seconds. The length of a record is limited to 30 seconds at least and truncated 2 hours at most. Up to 12-hour data can be recorded.
F. Resistance to interference of surrounding light:
The difference between the value measured in the condition of indoor natural light and that of darkroom is less than ±1%.
G.Resistance to 50Hz/60Hz interference
SpO2 and PR are precise which have been tested by BIO-TEK pulse oximeter simulator
H. Dimensions:
145 mm (L) × 74 mm (W) × 29 mm (H)
Net Weight: 140g (not including batteries and accessories)
1.A probe)
2.A holder)
3.Battery(AA)× 3)
4.A User Manual)
5.A Quality Certificate)
6.A data cable (optional))
7.Oximeter Data Manager software (optional
